System description
Labeling strips:
Labeling strips for labeling buttons 1 to 4 are included:
• 6 pre-assigned labeling strips and 1 individually inscribable labeling strip
Button 1
Button 2
Button 3
Button 4
Fig. 1-12: Labeling strips for the buttons of the operator panel with display
1-36
I
0
0
0
CLOSE
OPEN
OPEN
STOP
CLOSE
SIMOCODE pro
GWA 4NEB 631 6050-22 DS 03
