Exti Register Map; Table 21. External Interrupt/Event Controller Register Map And Reset Values - ST STM32F207 Series Reference Manual

RM0033
8.3.7

EXTI register map

Table 21

Table 21. External interrupt/event controller register map and reset values

Offset Register
EXTI_IMR
0x00
Reset value
EXTI_EMR
0x04
Reset value
EXTI_RTSR
0x08
Reset value
EXTI_FTSR
0x0C
Reset value
EXTI_SWIER
0x10
Reset value
EXTI_PR
0x14
Reset value
Refer to
gives the EXTI register map and the reset values.
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Section 2.3 on page 51
0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0
for the register boundary addresses.
RM0033 Rev 9
Interrupts and events
MR[22:0]
0 0 0 0 0 0 0 0 0
MR[22:0]
0 0 0 0 0 0 0 0 0
TR[22:0]
0 0 0 0 0 0 0 0 0
TR[22:0]
0 0 0 0 0 0 0 0 0
SWIER[22:0]
0 0 0 0 0 0 0 0 0
PR[22:0]
0 0 0 0 0 0 0 0 0
0 0 0 0 0
0 0 0 0 0
0 0 0 0 0
0 0 0 0 0
0 0 0 0 0
0 0 0 0 0
175/1381
