DCMI data register (DCMI_DR)

Address offset: 0x28
Reset value: 0x0000 0x0000
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10
Byte3
r r r r r r r
Bits 31:24 Data byte 3
Bits 23:16 Data byte 2
The digital camera Interface packages all the received data in 32-bit format before
requesting a DMA transfer. A 4-word deep FIFO is available to leave enough time for DMA
transfers and avoid DMA overrun conditions.
12.8.12

DCMI register map
