RM0033
Bits 7:4 HPRE: AHB prescaler
Set and cleared by software to control AHB clock division factor.
Caution: The clocks are divided with the new prescaler factor from 1 to 16 AHB cycles after
Caution: The AHB clock frequency must be at least 25 MHz when the Ethernet is used.
0xxx: system clock not divided
1000: system clock divided by 2
1001: system clock divided by 4
1010: system clock divided by 8
1011: system clock divided by 16
1100: system clock divided by 64
1101: system clock divided by 128
1110: system clock divided by 256
1111: system clock divided by 512
Bits 3:2 SWS: System clock switch status
Set and cleared by hardware to indicate which clock source is used as the system clock.
00: HSI oscillator used as the system clock
01: HSE oscillator used as the system clock
10: PLL used as the system clock
11: not applicable
Bits 1:0 SW: System clock switch
Set and cleared by software to select the system clock source.
Set by hardware to force the HSI selection when leaving the Stop or Standby mode or in
case of failure of the HSE oscillator used directly or indirectly as the system clock.
00: HSI oscillator selected as system clock
01: HSE oscillator selected as system clock
10: PLL selected as system clock
11: not allowed
5.3.4

RCC clock interrupt register (RCC_CIR)

Address offset: 0x0C
Reset value: 0x0000 0000
Access: no wait state, word, half-word and byte access
31 30 29
15 14 13
PLLI2S
RDYIE RDYIE
Reserved
rw
HPRE write.
28 27 26 25
Reserved
12 11 10 9
PLL HSE HSI LSE
RDYIE RDYIE RDYIE
rw rw rw rw
24 23 22
PLLI2S
CSSC
Reserv
RDYC
ed
w
8 7 6
LSI PLLI2S
CSSF
RDYIE RDYF
Reserv
ed
rw r
RM0033 Rev 9
Reset and clock control (RCC)
21 20 19 18
PLL HSE HSI
RDYC RDYC RDYC
w w w w
5 4 3 2
PLL HSE HSI
RDYF RDYF RDYF
r r r r
17 16
LSE LSI
RDYC RDYC
w w
1 0
LSE LSI
RDYF RDYF
r r
101/1381
