ST STM32F207 Series Reference Manual page 819

RM0033
Bits 1:0 FMP0[1:0]
CAN receive FIFO 1 register (CAN_RF1R)
Address offset: 0x10
Reset value: 0x0000 0000
31 30 29
15 14 13
Bits 31:6 Reserved, must be kept at reset value.
Bit 5 RFOM1
Bit 4 FOVR1
Bit 3 FULL1
Bit 2 Reserved, must be kept at reset value.
Bits 1:0 FMP1[1:0]
CAN interrupt enable register (CAN_IER)
Address offset: 0x14
Reset value: 0x0000 0000
31 30 29
15 14 13
ERRIE
Reserved
rw
:
FIFO 0 message pending
These bits indicate how many messages are pending in the receive FIFO.
FMP is increased each time the hardware stores a new message in to the FIFO. FMP is
decreased each time the software releases the output mailbox by setting the RFOM0 bit.
28 27 26 25
12 11 10 9
Reserved
:
Release FIFO 1 output mailbox
Set by software to release the output mailbox of the FIFO. The output mailbox can only be
released when at least one message is pending in the FIFO. Setting this bit when the FIFO
is empty has no effect. If at least two messages are pending in the FIFO, the software has to
release the output mailbox to access the next message.
Cleared by hardware when the output mailbox has been released.
:
FIFO 1 overrun
This bit is set by hardware when a new message has been received and passed the filter
while the FIFO was full.
This bit is cleared by software.
:
FIFO 1 full
Set by hardware when three messages are stored in the FIFO.
This bit is cleared by software.
:
FIFO 1 message pending
These bits indicate how many messages are pending in the receive FIFO1.
FMP1 is increased each time the hardware stores a new message in to the FIFO1. FMP is
decreased each time the software releases the output mailbox by setting the RFOM1 bit.
28 27 26 25
Reserved
12 11 10 9
LEC BOF EPV
IE IE IE
rw rw rw
24 23 22
Reserved
8 7 6
RFOM1 FOVR1 FULL1
24 23 22
8 7 6
EWG FOV
IE IE1
Res.
rw rw
RM0033 Rev 9
Controller area network (bxCAN)
21 20 19 18
5 4 3 2
Res.
rs rc_w1 rc_w1
21 20 19 18
5 4 3 2
FF FMP FOV FF
IE1 IE1 IE0 IE0
rw rw rw rw
17 16
1 0
FMP1[1:0]
r r
17 16
SLKIE WKUIE
rw rw
1 0
FMP TME
IE0 IE
rw rw
819/1381
