Hash Interrupt; Figure 214. Hash Interrupt Mapping Diagram - ST STM32F207 Series Reference Manual

Hash processor (HASH)
Procedure where the data are loaded by DMA
In this case it is not possible to predict if a DMA transfer is in progress or if the process is
ongoing. Thus, you must stop the DMA transfers, then wait until the HASH is ready in order
to interrupt the processing of a message.
•
Interrupting a processing:
–
–
–
–
•
The context saving and context restoring phases are the same as above (see
Procedure where the data are loaded by
Reconfigure the DMA controller so that it transfers the end of the message. You can now
restart the processing from the point where it was interrupted by setting the DMAE bit.
Note: If context swapping does not involve HMAC operations, the HASH_CSR38 to
HASH_CSR50 registers do not have to be saved and restored.
If context swapping occurs between two blocks (the last block was completely processed
and the next block has not yet been pushed into the IN FIFO, NBW = 000 in the HASH_CR
register), the HASH_CSR22 to HASH_CSR37 registers do not have to be saved and
restored.
21.3.8

HASH interrupt

There are two individual maskable interrupt sources generated by the HASH processor.
They are connected to the same interrupt vector.
You can enable or disable the interrupt sources individually by changing the mask bits in the
HASH_IMR register. Setting the appropriate mask bit to 1 enables the interrupt.
The status of the individual interrupt sources can be read from the HASH_SR register.
558/1381
Clear the DMAE bit to disable the DMA interface
Wait until the current DMA transfer is complete (wait for DMAES = 0 in the
HASH_SR register). Note that the block may or not have been totally transferred
to the HASH.
Disable the corresponding channel in the DMA controller
Wait until the hash processor is ready (no block is being processed), that is wait
for DINIS = 1

Figure 214. HASH interrupt mapping diagram

DCIS
DCIM
DINIS
DINIM
software).
RM0033 Rev 9
HASH interrupt to NVIC
ai16086
