Serial peripheral interface (SPI)
25.5.10

SPI register map

The table provides shows the SPI register map and reset values.
Offset Register
SPI_CR1
0x00
Reset value
SPI_CR2
0x04
Reset value
SPI_SR
0x08
Reset value
SPI_DR
0x0C
Reset value
SPI_CRCPR
0x10
Reset value
SPI_RXCRCR
0x14
Reset value
SPI_TXCRCR
0x18
Reset value
SPI_I2SCFGR
0x1C
Reset value
SPI_I2SPR
0x20
Reset value
Refer to
734/1381

Table 102. SPI register map and reset values
