RM0033
slave transmission mode, this flag is not reliable and I
switched on before resuming the communication.
In reception mode, this flag is refreshed when data are received into SPI_DR. It indicates
from which channel side data have been received. Note that in case of error (like OVR) this
flag becomes meaningless and the I
(with configuration if it needs changing).
This flag has no meaning in the PCM standard (for both Short and Long frame modes).
When the OVR or UDR flag in the SPI_SR is set and the ERRIE bit in SPI_CR2 is also set,
an interrupt is generated. This interrupt can be cleared by reading the SPI_SR status
register (once the interrupt source has been cleared).
25.4.7

Error flags

There are two error flags for the I
Underrun flag (UDR)
In slave transmission mode this flag is set when the first clock for data transmission appears
while the software has not yet loaded any value into SPI_DR. It is available when the
I2SMOD bit in SPI_I2SCFGR is set. An interrupt may be generated if the ERRIE bit in
SPI_CR2 is set.
The UDR bit is cleared by a read operation on the SPI_SR register.
Overrun flag (OVR)
This flag is set when data are received and the previous data have not yet been read from
SPI_DR. As a result, the incoming data are lost. An interrupt may be generated if the ERRIE
bit is set in SPI_CR2.
In this case, the receive buffer contents are not updated with the newly received data from
the transmitter device. A read operation to the SPI_DR register returns the previous
correctly received data. All other subsequently transmitted half-words are lost.
Clearing the OVR bit is done by a read operation on the SPI_DR register followed by a read
access to the SPI_SR register.
2
25.4.8 I S interrupts
Table 101
Transmit buffer empty flag
Receive buffer not empty flag
Overrun error
Underrun error
2
provides the list of I S interrupts.

Table 101. I

Interrupt event
2
2
S should be reset by disabling and then enabling it
2
S cell.
2
S interrupt requests
Event flag
TXE
RXNE
OVR
UDR
RM0033 Rev 9
Serial peripheral interface (SPI)
S needs to be switched off and
Enable Control bit
TXEIE
RXNEIE
ERRIE
723/1381
