Regular Simultaneous Mode; Figure 36. Injected Simultaneous Mode On 4 Channels: Dual Adc Mode; Figure 37. Injected Simultaneous Mode On 4 Channels: Triple Adc Mode - ST STM32F207 Series Reference Manual

Advanced arm-based 32-bit mcus

Hide thumbs Also See for STM32F207 Series:

Table of Contents

Dual ADC mode

At the end of conversion event on ADC1 or ADC2:

The converted data are stored into the ADC_JDRx registers of each ADC interface.

A JEOC interrupt is generated (if enabled on one of the two ADC interfaces) when the

ADC1/ADC2's injected channels have all been converted.

Triple ADC mode

At the end of conversion event on ADC1, ADC2 or ADC3:

The converted data are stored into the ADC_JDRx registers of each ADC interface.

A JEOC interrupt is generated (if enabled on one of the three ADC interfaces) when the

ADC1/ADC2/ADC3's injected channels have all been converted.

Regular simultaneous mode

This mode is performed on a regular group of channels. The external trigger source comes

from the regular group multiplexer of ADC1 (selected by the EXTSEL[3:0] bits in the

ADC1_CR2 register). A simultaneous trigger is provided to ADC2 and ADC3.

Do not convert the same channel on the two/three ADCs (no overlapping sampling times for

the two/three ADCs when converting the same channel).

In regular simultaneous mode, one must convert sequences with the same length or ensure

that the interval between triggers is longer than the long conversion time of the 2 sequences

(Dual ADC mode) /3 sequences (Triple ADC mode). Otherwise, the ADC with the shortest

sequence may restart while the ADC with the longest sequence is completing the previous

conversions.

Injected conversions must be disabled.

End of conversion on ADC1 and ADC2

End of conversion on ADC1, ADC2 and ADC3

RM0033 Rev 9

Analog-to-digital converter (ADC)
