Parameter Lists

5 Parameter Lists

5.1 Introduction

Frequency converter series
All = valid for FC 301 and FC 302 series
01 = valid for FC 301 only
02 = valid for FC 302 only
Changes during operation
True means that the parameter can be changed while the
frequency converter is in operation. False means that the
frequency converter must be stopped before a change can
be made.
4 set-up
All set-ups: the parameter can be set individually in each
of the 4 set-ups, for example 1 single parameter can have
4 different data values.
1 set-up: The data value is the same in all set-ups.
Data Description
type
2 Integer 8
3 Integer 16
4 Integer 32
5 Unsigned 8
6 Unsigned 16
7 Unsigned 32
9 Visible string
33 Normalized value 2 bytes
35 Bit sequence of 16 boolean variables
54 Time difference w/o date
Table 5.1 Data Type
5.1.1 Conversion
The various attributes of each parameter are shown in
factory setting. Parameter values are transferred as whole
numbers only. Conversion factors are therefore used to
transfer decimals.

5.2 Parameter Lists and Options, Software Version 8.10 (Standard)

5.2.1 0-** Operation / Display
Para Parameter description
mete
r
num
ber
0-0* Basic Settings
0-01 Language
0-02 Motor Speed Unit
0-03 Regional Settings
MG33MO02
Programming Guide
A conversion factor of 0.1 means that the value transferred
is multiplied by 0.1. The value 100 is therefore read as 10.0.
Conversion index
100
75
74
70
67
6
5
4
3
2
1
0
Type
-1
-2
Int8
-3
Int16
-4
Int32
-5
Uint8
-6
Uint16
Table 5.2 Conversion Table
Uint32
VisStr
N2
V2
TimD
Default value 4 set-up
[0] English 1 set-up
ExpressionLimit 2 set-ups
[0] International 2 set-ups
Danfoss A/S © 01/2018 All rights reserved.
Conversion factor
1
3600000
3600
60
1/60
1000000
100000
10000
1000
100
10
1
0.1
0.01
0.001
0.0001
0.00001
0.000001
FC 302 only Change Conversio
during n index
operation
TRUE -
FALSE -
FALSE -
5 5
Type
Uint8
Uint8
Uint8
227
