APPENDIX B

RECOMMENDED UNUSED PIN CONFIGURATIONS

Table 75. Recommended Configuration of Unused Pins
Pin No. Mnemonic Type
0 GND Ground
1 GND Ground
2 CVDD Power
3 RXA_C- HDMI Input
4 RXA_C+ HDMI Input
5 TVDD Power
6 RXA_0- HDMI Input
7 RXA_0+ HDMI Input
8 TVDD Power
9 RXA_1- HDMI Input
10 RXA_1+ HDMI input
11 TVDD Power
12 RXA_2- HDMI Input
13 RXA_2+ HDMI Input
14 CVDD Power
15 GND Ground
16 TEST1 No Connect
17 DVDD Power
18 TEST2 No Connect
19 CVDD Power
20 RXB_C- HDMI Input
21 RXB_C+ HDMI Input
22 TVDD Power
23 RXB_0- HDMI Input
24 RXB_0+ HDMI Input
25 TVDD Power
26 RXB_1- HDMI Input
27 RXB_1+ HDMI Input
28 TVDD Power
29 RXB_2- HDMI Input
30 RXB_2+ HDMI Input
31 CVDD Power
32 GND Ground
33 NC No Connect
34 DVDD Power
35 P47 Digital Output
36 P46 Digital Output
37 P45 Digital Output
38 P44 Digital Output
39 P43 Digital Output
40 DVDDIO Power
41 P42 Digital Output
42 P41 Digital Output
43 P40 Digital Output
44 P39 Digital Output
45 P38 Digital Output
46 P37 Digital Output
47 P36 Digital Output
48 P35 Digital Output
Recommended Configuration if Not Used
Ground
Ground
HDMI Analog Block Supply Voltage (1.8 V)
Float this pin
Float this pin
Terminator Supply Voltage (3.3 V)
Float this pin
Float this pin
Terminator Supply Voltage (3.3 V)
Float this pin
Float this pin
Terminator Supply Voltage (3.3 V)
Float this pin
Float this pin
HDMI Analog Block Supply Voltage (1.8 V)
Ground
Float this pin
Digital Core Supply Voltage (1.8 V)
Float this pin
HDMI Analog Block Supply Voltage (1.8 V)
Float this pin
Float this pin
Terminator Supply Voltage (3.3 V)
Float this pin
Float this pin
Terminator Supply Voltage (3.3 V)
Float this pin
Float this pin
Terminator Supply Voltage (3.3 V)
Float this pin
Float this pin
HDMI Analog Block Supply Voltage (1.8 V)
Ground
Float this pin
Digital Core Supply Voltage (1.8 V)
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Digital I/O Supply Voltage (3.3 V)
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
Float this pin
