Recommended Unused Pin Configurations - Analog Devices ADV7610 Hardware User's Manual

UG-438
APPENDIX B

RECOMMENDED UNUSED PIN CONFIGURATIONS

Table 71. Recommended Configuration of Unused Pins
Ball No.
D4, D5, D6, E4, F4, G4, G5, G6
A1
G1, G2
B1, B2
F7, G7, J10, K10
A10, B10, D7, E7
A4
C2
C1
D2
D1
E2
E1
F2
F1
H1
H2
J1
K1
K2
J2
K3
J3
K4
J4
K5
J5
K6
J6
K7
J7
K8
J8
K9
J9
H10
H9
G10
G9
F10
E10
F9
E9
D10, C10, D9, C9
A9
B9
A8
B8
B7
Mnemonic Type
GND Ground
HPA_A/INT2 Miscellaneous digital
CVDD Power
TVDD Power
DVDDIO Power
DVDD Power
PVDD Power
RXA_C− HDMI input
RXA_C+ HDMI input
RXA_0− HDMI input
RXA_0+ HDMI input
RXA_1− HDMI input
RXA_1+ HDMI input
RXA_2− HDMI input
RXA_2+ HDMI input
P23 Digital video output
P22 Digital video output
P21 Digital video output
P20 Digital video output
P19 Digital video output
P18 Digital video output
P17 Digital video output
P16 Digital video output
LLC Digital video output
P15 Digital video output
P14 Digital video output
P13 Digital video output
P12 Digital video output
P11 Digital video output
P10 Digital video output
P9 Digital video output
P8 Digital video output
P7 Digital video output
P6 Digital video output
P5 Digital video output
P4 Digital video output
P3 Digital video output
P2 Digital video output
P1 Digital video output
P0 Digital video output
DE Miscellaneous digital
HS Digital video output
VS/FIELD/ALSB Digital input/output
I 2 S0 to I 2 S3 Miscellaneous digital
SCLK/INT2 Miscellaneous digital
LRCLK Miscellaneous digital
MCLK/INT2 Miscellaneous digital
SCL Miscellaneous digital
SDA Miscellaneous digital
Description
Ground.
Float this pin.
This pin is always connected to comparator supply voltage (1.8 V).
This pin is always connected to comparator supply voltage (3.3 V).
This pin is always connected to comparator supply voltage (3.3 V).
This pin is always connected to comparator supply voltage (1.8 V).
This pin is always connected to comparator supply voltage (1.8 V).
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
This pin is always connected to the pixel clock input.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
Float this pin.
This pin is always connected to the I
This pin is always connected to the I
Rev. 0 | Page 180 of 184
Hardware User Guide
2 C clock line of a control processor.
C data line of a control processor.
2
