Error Source Code
Primary Fault 233
Primary Fault 261
Primary Fault 262
Primary Fault 263
Inverter Fault 265
Inverter Fault 266
Inverter Fault 267
Inverter Fault 268
Inverter Fault 269
Inverter Fault 270
Inverter Fault 271
Inverter Fault 272
Inverter Fault 273
Inverter Fault 274
Inverter Fault 275
Inverter Fault 276
Inverter Fault 277

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
AFX Series Power Source Operation Manual
Category Error Message
Error Invalid constants loaded
from EEPROM.
Error Controller is not in
operational node.
Error Missing controller node.
Error Cannot read fault
information.
Error Inverter gate driver fault.
Error Internal bias supply fault.
Error No waveform loaded.
Load waveform before
enabling arbitrary
waveform mode.
Error Exceeded RMS current
limit.
Error Exceeded active power
limit.
Error Exceeded apparent
power limit.
Error Internal SCIA
communication error.
Error Internal McBSP
communication CRC
error.
Error Inverter current negative
peak protection.
Error Inverter current positive
peak protection.
Error DC bus voltage minimum
limit exceeded.
Error DC bus voltage maximum
limit exceeded.
Error Temperature protection
AFX SERIES® OPERATION MANUAL
Service and Maintenance
SECTION 13:
Possible Cause
Calibration Coefficients
found are invalid.
An inconsistency was
detected in the power
source's internal
communication network.
An inconsistency was
detected in the power
source's internal
communication network.
Internal Communication
Error. Unable to read
fault info
Gate fault detected in
output inverter. Possible
overload or load kickback
Bias supply fault. Internal
Bias Supply fault occurred
Setting conflict. Trying to
select unavailable
arbitrary waveform
register for output
Overload condition.
Output inverter RMS
current exceeded
maximum limit.
Overload condition.
Output inverter real
power output exceeded
maximum limit.
Overload condition.
Output inverter apparent
power output exceeded
maximum limit.
Internal Communication
Error
Internal Communication
Error
Overload condition.
Output inverter negative
peak current exceeded
maximum limit.
Overload condition.
Output inverter positive
peak current exceeded
maximum limit.
Overload condition.
Internal DC Bus under
voltage protection
Overload condition.
Internal DC Bus
overvoltage protection
Over Temperature.
Output inverter stage
Resolution
SANITIZE unit to restore
factory defaults
Turn unit off, check
parallel cables if they
exist, and then turn unit
on. If problem recurs
contact customer service.
Turn unit off, check
parallel cables if they
exist, and then turn unit
on. If problem recurs
contact customer service.
Contact customer service
Reduce Load
Check for correct AC
input voltage connection.
Load waveform before
enabling arbitrary
waveform mode.
Check load.
Check load.
Check load.
Contact customer service
Contact customer service
Check load.
Check load.
Possible energy from load
being pushed back into
inverters.
Possible energy from load
being pushed back into
inverters.
Check load levels or
ambient temperature
