6.8.3

ERROR / EVENT QUEUE Screen

The Error and Event queue shows the history of any errors of events that have occurred
since the last time the error queue was cleared.
The error queue can be cleared using a SCPI command over any of the remote control
interfaces or by pressing the "Clear Queue" soft key while on this screen.
6.8.4

FAULT INFORMATION Screen

The fault list shows any logged internal operation faults. This information may be useful
when trouble shooting any issues with the power source. In that even, customer service
may request this information from the end user or request access to the instrument through
the LAN interface for further diagnostics.

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
AFX Series Power Source Operation Manual
Figure 6-25: ERROR & EVENT QUEUE Screen
Figure 6-26: FAULT INFORMATION screen
