Error Source Code
Front panel 86
Error
Front panel 89
Error
Front panel 90
Error
Front panel 91
Error
Front panel 92
Error
Front panel 93
Error
Front panel 94
Error
Front panel 95
Error
Front panel 96
Error
Front panel 97
Error
Front panel 98
Error
Front panel 99
Error
Front panel 100
Error
Front panel 101
Error
Front panel 102
Error
Front panel 103
Error
Front panel 104
Error
Front panel 105
Error
Front panel 106
Error

Entire Contents Copyright 2018 by Pacific Power Source, Inc. (PPS) • All Rights Reserved • No reproduction without written authorization from PPS.
AFX Series Power Source Operation Manual
Category Error Message
Error Unable to enable output.
One or more primary
stages failed to enable.
Error Digital I/O interface
conflict: Remote inhibit is
active.
Error Digital I/O interface
conflict: Remote enable is
active.
Error Internal error: Unknown
phase mode.
Error Unable to disable output.
One or more primary
stages failed to disable.
Error Internal error: Cannot
configure timer.
Error Internal error: Cannot
create timer.
Error Digital I/Os interface
conflict: Serial interface
flow control is active.
Error Data logger storage error.
Error Output enable in
progress.
Error DC Voltage not allowed in
"AC mode".
Error AC Voltage not allowed in
"DC mode".
Error DC voltage set point
cannot change due to
user limit.
Error AC voltage set point
cannot change due to
user limit.
Error DC voltage set point
cannot change due to low
range.
Error AC voltage set point
cannot change due to low
range.
Error Waveform change in
progress.
Error Error changing service
name
Error Error getting service
name
AFX SERIES® OPERATION MANUAL
Service and Maintenance
SECTION 13:
Possible Cause
Output ON failed due to
power input stage fault
Conflict between front
panel and Remote Inhibit
input level
Conflict between front
panel and Remote
Enable input level
Selected Phase Mode
(FORM) is unknown
Output OFF failed.
Attempt to disable one or
more inverter stages
failed
Timer Configuration Error
Timer Creation Error
RS232 or USB interface
error
Error saving
measurement data to
selecting memory device.
Memory device may have
been removed
Waiting to turn output
off. Changing from
Output ON to Output OFF
state
Setting conflict. Setting
does not match mode
Setting conflict. Setting
does not match mode
Setting conflict. Setting
outside of User Limits
Setting conflict. Setting
outside of User Limits
Setting conflict. Setting
outside of User Limits
Setting conflict. Setting
outside of User Limits
Waveform change in
progress
Internal Service Error.
Could not change service
Internal Service Error.
Could not get service
name
Resolution
Try recycling power. If
error persists, contact
customer service
Resolve conflict. Check
input to Remote Inhibit
Resolve conflict. Check
input to Remote Enable
Try recycling power. If
error persists, contact
customer service
Turn Unit off with Circuit
Breaker
Reset front panel
Reset front panel
Check RS232 or USB
settings
Check for Memory device
presence
Wait for power stages
and inverters to fully
engage
Check setting
Check setting
Check setting
Check setting
Check setting
Check setting
Wait
Try recycling power. If
error persists, contact
customer service
Try recycling power. If
error persists, contact
customer service
