Introduction
Overview
The Parts List section identifies all part numbers and the corresponding location of all spared
subsystem components.
Organization
Parts Lists
Each item number in the part number listing corresponds to an item number in the related
illustration. All the parts in a given subsystem of the machine will be located in the same
illustration or in a series of associated illustrations.
Electrical Connectors and Fasteners
This section contains the illustrations and descriptions of the plugs, jacks, and fasteners used
in the machine. A part number listing of the connectors is included.
Common Hardware
The common hardware is listed in alphabetical order by the letter or letters used to identify
each item in the part number listing and in the illustrations. Dimensions are in millimeters
unless otherwise identified.
Part Number Index
This index lists all the spared parts in the machine in numerical order. Each number is followed
by a reference to the parts list on which the part may be found.
Other Information
Abbreviations
Abbreviations are used in the parts lists and the exploded view illustrations to provide
information in a limited amount of space. The following abbreviations are used in this manual:
Table 1 Abbreviation size
Abbreviation
A3
297 x 594 Millimeters
A4
210 x 297 Millimeters
A5
148 x 210 Millimeters
AD
Auto Duplex
AWG
American Wire Gauge
EMI
Electro Magnetic Induction
GB
Giga Byte
KB
Kilo Byte
MB
Mega Byte
MM
Millimeters
MOD
Magneto Optical Drive
NOHAD
Noise Ozone Heat Air Dirt
PL
Parts List
P/O
Part of
Launch Version
WorkCentre 5225, 5230
Meaning
February, 2008
Table 1 Abbreviation size
Abbreviation
R/E
Reduction/Enlargement
REF:
Refer to
SCSI
Small Computer Systems Interface
W/
With
W/O
Without
Operating Companies
Abbreviation
AO
Americas Operations
NASG - US
North American Solutions Group - US
NASG -
North American Solutions Group -
Canada
Canada
XE
Xerox Europe
Symbology
Symbology used in the Parts List section is identified in the Symbology section.
Service Procedure Referencing
If a part or assembly has an associated repair or adjustment procedure, the procedure number
will be listed at the end of the part description in the parts lists e.g. (REP 5.1, ADJ 5.3)
5-3
Meaning
Table 2 Meaning
Meaning
Introduction
Parts List
