19.8.3
Control C - Split Mode
Name: 
CTRLC
Offset: 
0x02
Reset: 
0x00
Property:  -
Bit
7
Access
Reset
Bit 6 – HCMP2OV High byte Compare 2 Output Value
See LCMP0OV.
Bit 5 – HCMP1OV High byte Compare 1 Output Value
See LCMP0OV.
Bit 4 – HCMP0OV High byte Compare 0 Output Value
See LCMP0OV.
Bit 2 – LCMP2OV Low byte Compare 2 Output Value
See LCMP0OV.
Bit 1 – LCMP1OV Low byte Compare 1 Output Value
See LCMP0OV.
Bit 0 – LCMP0OV Low byte Compare 0 Output Value
The LCMPnOV/HCMPn bits allow direct access to the waveform generator's output compare value when
the timer/counter is not enabled. This is used to set or clear the WOn output value when the timer/counter
is not running.
©
2018 Microchip Technology Inc.
6
5
HCMP2OV
HCMP1OV
R/W
R/W
0
0
16-bit Timer/Counter Type A (TCA)
4
3
HCMP0OV
R/W
0
Datasheet Preliminary
®
megaAVR
0-Series
2
1
LCMP2OV
LCMP1OV
R/W
R/W
0
0
DS40002015A-page 221
0
LCMP0OV
R/W
0
