29.5.3 Control A
Name: CTRLA
Offset: 0x02
Reset: 0x00
Property: -
Bit 7
IBDLY
Access R/W
Reset 0
Bit 7 – IBDLY Inter-Byte Delay Enable
Writing a '1' to this bit enables a fixed inter-byte delay between each data byte transmitted from the UPDI
when doing multi-byte LD(S). The fixed length is two IDLE characters. Before the first transmitted byte,
the regular GT delay used for direction change will be used.
Bit 5 – PARD Parity Disable
Writing this bit to '1' will disable parity detection in the UPDI by ignoring the Parity bit. This feature is
recommended only during testing.
Bit 4 – DTD Disable Time-out Detection
Setting this bit disables the time-out detection on the PHY layer, which requests a response from the ACC
layer within a specified time (65536 UPDI clock cycles).
Bit 3 – RSD Response Signature Disable
Writing a '1' to this bit will disable any response signatures generated by the UPDI. This is to reduce the
protocol overhead to a minimum when writing large blocks of data to the NVM space. Disabling the
Response Signature should be used with caution, and only when the delay experienced by the UPDI
when accessing the system bus is predictable, otherwise loss of data may occur.
Bits 2:0 – GTVAL[2:0] Guard Time Value
This bit field selects the Guard Time Value that will be used by the UPDI when the transmission mode
switches from RX to TX.
Value Description
0x0 UPDI Guard Time: 128 cycles (default)
0x1 UPDI Guard Time: 64 cycles
0x2 UPDI Guard Time: 32 cycles
0x3 UPDI Guard Time: 16 cycles
0x4 UPDI Guard Time: 8 cycles
0x5 UPDI Guard Time: 4 cycles
0x6 UPDI Guard Time: 2 cycles
0x7 GT off (no extra Idle bits inserted)
©
