28.5.3
Control C
Name:
CTRLC
Offset:
0x02
Reset:
0x00
Property: -
Bit
7
Access
R
Reset
0
Bit 6 – SAMPCAP Sample Capacitance Selection
This bit selects the sample capacitance, and hence, the input impedance. The best value is dependent on
the reference voltage and the application's electrical properties.
Value
Description
0
Recommended for reference voltage values below 1V.
1
Reduced size of sampling capacitance. Recommended for higher reference voltages.
Bits 5:4 – REFSEL[1:0] Reference Selection
These bits select the voltage reference for the ADC.
Value
Name
0x0
INTERNAL
0x1
VDD
0x2
VREFA
Other
-
Bits 2:0 – PRESC[2:0] Prescaler
These bits define the division factor from the peripheral clock (CLK_PER) to the ADC clock (CLK_ADC).
Value
Name
0x0
DIV2
0x1
DIV4
0x2
DIV8
0x3
DIV16
0x4
DIV32
0x5
DIV64
0x6
DIV128
0x7
DIV256
©
2018 Microchip Technology Inc.
6
5
SAMPCAP
REFSEL[1:0]
R/W
R/W
0
0
Description
CLK_PER divided by 2
CLK_PER divided by 4
CLK_PER divided by 8
CLK_PER divided by 16
CLK_PER divided by 32
CLK_PER divided by 64
CLK_PER divided by 128
CLK_PER divided by 256
Analog-to-Digital Converter (ADC)
4
3
R/W
R
0
0
Description
Internal reference
V
DD
External reference V
REFA
Reserved.
Datasheet Preliminary
®
megaAVR
0-Series
2
1
PRESC[2:0]
R/W
R/W
0
0
DS40002015A-page 424
