9.5.5 20 MHz Oscillator Control A
Name: OSC20MCTRLA
Offset: 0x10
Reset: 0x00
Property: Configuration Change Protection
Bit 7
Access
Reset
Bit 1 – RUNSTDBY Run Standby
This bit forces the oscillator ON in all modes, even when unused by the system. In Standby Sleep mode
this can be used to ensure immediate wake-up and not waiting for oscillator start-up time.
When not requested by peripherals, no oscillator output is provided.
It takes four oscillator cycles to open the clock gate after a request but the oscillator analog start-up time
will be removed when this bit is set.
©
2018 Microchip Technology Inc.
6 5 4 3
Datasheet Preliminary
®
megaAVR 0-Series
Clock Controller (CLKCTRL)
2 1
RUNSTDBY
R/W
0
DS40002015A-page 88
0
