14.3.6 PORTMUX Control for TCB
Name: TCBROUTEA
Offset: 0x05
Reset: 0x00
Property: -
Bit 7
Access
Reset
Bit 3 – TCB3 TCB3 output
Write this bit to '1' to select alternative output pin for 16-bit timer/counter B 3.
Value Name
0x0 DEFAULT
0x1 ALT1
Bit 2 – TCB2 TCB2 output
Write this bit to '1' to select alternative output pin for 16-bit timer/counter B 2.
Value Name
0x0 DEFAULT
0x1 ALT1
Bit 1 – TCB1 TCB1 output
Write this bit to '1' to select alternative output pin for 16-bit timer/counter B 1.
Value Name
0x0 DEFAULT
0x1 ALT1
Bit 0 – TCB0 TCB0 output
Write this bit to '1' to select alternative output pin for 16-bit timer/counter B 0.
Value Name
0x0 DEFAULT
0x1 ALT1
©
2018 Microchip Technology Inc.
6 5 4 3
TCB3
R/W
0
Description
TCB3 on PB5
TCB3 on PC1
Description
TCB2 on PC0
TCB2 on PB4
Description
TCB1 on PA3
TCB1 on PF5
Description
TCB0 on PA2
TCB0 on PF4
Datasheet Preliminary
®
megaAVR 0-Series
Port Multiplexer (PORTMUX)
2 1
TCB2 TCB1
R/W R/W
0 0
DS40002015A-page 136
0
TCB0
R/W
0
