Register Summary - Portx; Register Description - Ports - Microchip Technology megaAVR 0 Series Manual

15.4

Register Summary - PORTx

Offset Name Bit Pos.
0x00 DIR
0x01 DIRSET
0x02 DIRCLR
0x03 DIRTGL
0x04 OUT
0x05 OUTSET
0x06 OUTCLR
0x07 OUTTGL
0x08 IN
0x09 INTFLAGS
0x0A PORTCTRL
0x0B
... Reserved
0x0F
0x10 PIN0CTRL
0x11 PIN1CTRL
0x12 PIN2CTRL
0x13 PIN3CTRL
0x14 PIN4CTRL
0x15 PIN5CTRL
0x16 PIN6CTRL
0x17 PIN7CTRL
15.5

Register Description - Ports

©
2018 Microchip Technology Inc.
7:0
7:0
7:0
7:0
7:0
7:0
7:0
7:0
7:0
7:0
7:0
7:0 INVEN
7:0 INVEN
7:0 INVEN
7:0 INVEN
7:0 INVEN
7:0 INVEN
7:0 INVEN
7:0 INVEN
DIR[7:0]
DIRSET[7:0]
DIRCLR[7:0]
DIRTGL[7:0]
OUT[7:0]
OUTSET[7:0]
OUTCLR[7:0]
OUTTGL[7:0]
IN[7:0]
INT[7:0]
PULLUPEN
PULLUPEN
PULLUPEN
PULLUPEN
PULLUPEN
PULLUPEN
PULLUPEN
PULLUPEN
Datasheet Preliminary
®
megaAVR 0-Series
I/O Pin Configuration (PORT)
ISC[2:0]
ISC[2:0]
ISC[2:0]
ISC[2:0]
ISC[2:0]
ISC[2:0]
ISC[2:0]
ISC[2:0]
DS40002015A-page 142
SRL
