15.5.2 Data Direction Set
Name: DIRSET
Offset: 0x01
Reset: 0x00
Property: -
Bit 7
Access R/W
Reset 0
Bits 7:0 – DIRSET[7:0] Data Direction Set
This bit field can be used instead of a read-modify-write to set individual pins as output.
Writing a '1' to DIRSET[n] will set the corresponding PORTx.DIR[n] bit.
Reading this bit field will always return the value of PORTx.DIR.
©
2018 Microchip Technology Inc.
6 5
R/W R/W
0 0
4 3
DIRSET[7:0]
R/W R/W
0 0
Datasheet Preliminary
®
megaAVR 0-Series
I/O Pin Configuration (PORT)
2 1
R/W R/W
0 0
DS40002015A-page 144
0
R/W
0
