28.5.7 MUXPOS
Name: MUXPOS
Offset: 0x06
Reset: 0x00
Property: -
Bit 7
Access
Reset
Bits 4:0 – MUXPOS[4:0] MUXPOS
This bit field selects which single-ended analog input is connected to the ADC. If these bits are changed
during a conversion, the change will not take effect until this conversion is complete.
MUXPOS
0x00-0x0F
0x10-0x1B
0x1C
0x1D
0x1E
0x1F
Other
©
2018 Microchip Technology Inc.
6 5
Name
AIN0-AIN15
-
DACREF0
-
TEMPSENSE
GND
-
Analog-to-Digital Converter (ADC)
4 3
MUXPOS[4:0]
R/W R/W
0 0
Input
ADC input pin 0 - 15
Reserved
DAC reference in AC0
Reserved
Temperature Sensor
GND
Reserved
Datasheet Preliminary
®
megaAVR 0-Series
2 1
R/W R/W
0 0
DS40002015A-page 428
0
R/W
0
