22.5.10 Baud Register
Name: BAUD
Offset: 0x08
Reset: 0x00
Property: -
The USARTn.BAUDL and USARTn.BAUDH register pair represents the 16-bit value, USARTn.BAUD.
The low byte [7:0] (suffix L) is accessible at the original offset. The high byte [15:8] (suffix H) can be
accessed at offset + 0x01.
Ongoing transmissions of the transmitter and receiver will be corrupted if the baud rate is changed.
Writing this register will trigger an immediate update of the baud rate prescaler. For more information on
how to set the baud rate, see
Bit 15
Access R/W
Reset 0
Bit 7
Access R/W
Reset 0
Bits 15:8 – BAUD[15:8] USART Baud Rate High Byte
These bits hold the MSB of the 16-bit Baud register.
Bits 7:0 – BAUD[7:0] USART Baud Rate Low Byte
These bits hold the LSB of the 16-bit Baud register.
©
2018 Microchip Technology Inc.
Universal Synchronous and Asynchronous Recei...
Table 22-1.
14 13
R/W R/W
0 0
6 5
R/W R/W
0 0
12 11
BAUD[15:8]
R/W R/W
0 0
4 3
BAUD[7:0]
R/W R/W
0 0
Datasheet Preliminary
®
megaAVR 0-Series
10 9
R/W R/W
0 0
2 1
R/W R/W
0 0
DS40002015A-page 312
8
R/W
0
0
R/W
0
