15.5.5 Output Value
Name: OUT
Offset: 0x04
Reset: 0x00
Property: -
Bit 7
Access R/W
Reset 0
Bits 7:0 – OUT[7:0] Output Value
This bit field defines the data output value for the individual pins of the port.
If OUT[n] is written to '1', pin n is driven high.
If OUT[n] is written to '0', pin n is driven low.
In order to have any effect, the pin direction must be configured as output.
©
2018 Microchip Technology Inc.
6 5
R/W R/W
0 0
4 3
OUT[7:0]
R/W R/W
0 0
Datasheet Preliminary
®
megaAVR 0-Series
I/O Pin Configuration (PORT)
2 1
R/W R/W
0 0
DS40002015A-page 147
0
R/W
0
