14.3.5 PORTMUX Control for TCA
Name: TCAROUTEA
Offset: 0x04
Reset: 0x00
Property: -
Bit 7
Access
Reset
Bits 2:0 – TCA0[2:0] TCA0
Write these bits to select alternative output pins for TCA0.
Value Name
0x0 PORTA
0x1 PORTB
0x2 PORTC
0x3 PORTD
0x4 PORTE
0x5 PORTF
Other -
©
2018 Microchip Technology Inc.
6 5
Description
TCA0 pins on PA[5:0]
TCA0 pins on PB[5:0]
TCA0 pins on PC[5:0]
TCA0 pins on PD[5:0]
TCA0 pins on PE[5:0]
TCA0 pins on PF[5:0]
Reserved
4 3
Datasheet Preliminary
®
megaAVR 0-Series
Port Multiplexer (PORTMUX)
2 1
TCA0[2:0]
R/W R/W
0 0
DS40002015A-page 135
0
R/W
0
