14.3.2 PORTMUX Control for CCL
Name: CCLROUTEA
Offset: 0x01
Reset: 0x00
Property: -
Bit 7
Access
Reset
Bit 3 – LUT3 CCL LUT 3 output
Write this bit to '1' to select alternative pin location for CCL LUT 3.
Value Name
0x0 DEFAULT
0x1 ALT1
Bit 2 – LUT2 CCL LUT 2 output
Write this bit to '1' to select alternative pin location for CCL LUT 2.
Value Name
0x0 DEFAULT
0x1 ALT1
Bit 1 – LUT1 CCL LUT 1 output
Write this bit to '1' to select alternative pin location for CCL LUT 1.
Value Name
0x0 DEFAULT
0x1 ALT1
Bit 0 – LUT0 CCL LUT 0 output
Write this bit to '1' to select alternative pin location for CCL LUT 0.
Value Name
0x0 DEFAULT
0x1 ALT1
©
