M120 Multiservice Edge Router Hardware Guide

RJ-45 Connector Pinouts for the Routing Engine AUX and CONSOLE Ports

Related
Documentation

RJ-45 Connector Pinouts for the External Clock Ports

248
All manuals and user guides at all-guides.com
Maintaining M120 PICs and PIC Cables on page 112
Installing an M120 PIC Cable on page 166
M120 PICs Description on page 15
The ports on the craft interface labeled
Ethernet RJ-45 receptacles that accept an RJ-45/DB-9 cable for connecting the Routing
Engine to a management LAN (or other device that supports out-of-band management).
Table 37 on page 248 describes the RJ-45 connector pinouts.
Table 37: RJ-45 Connector Pinout for the Routing Engine AUX and
CONSOLE Ports
Pin Signal
1 RTS
2 DTR
3 TXD
4 Ground
5 Ground
6 RXD
7 DSR/DCD
8 CTS
Replacing the Console or Auxiliary Cable on the M120 Routing Engine on page 133
Maintaining M120 PICs and PIC Cables on page 112
Installing an M120 PIC Cable on page 166
M120 PICs Description on page 15
The External Interface clock connector uses an RJ-45 connector. Table 38 on page 249
describes the pinouts for the RJ-45 connector.
AUX and CONSOLE are autosensing 10/100-Mbps
Description
Request to Send
Data Terminal Ready
Transmit Data
Signal Ground
Signal Ground
Receive Data
Data Set Ready
Clear to Send
Copyright © 2010, Juniper Networks, Inc.
