CDM-570/570L Satellite Modem with Optional IP Module
IP Module Ethernet Interface Overview
•
Configuration backup and restore via FTP
•
Event Logging to capture all IP Module activity
•
Detailed Statistics of IP traffic
•
IGMP support for multicast
•
CDM-550 Emulation Mode
•
Static IP routing for unicast and multicast
•
easyConnect™ Mode
15.3.1

10/100BaseT Ethernet Interface

In Router Mode operation, the 10/100BaseT Ethernet Interface is used for routing IP
traffic to be transmitted over the satellite or routed to another device on the local LAN. In
easyConnect™ Mode, the Ethernet Interface is used to forward IP and non-IP traffic over
the satellite. Local or remote management of all CDM-570/570L and IP Module
functions is also available via Telnet, HTTP, or SNMP.
15.3.2

Powerful Network Management

The CDM-570/570L IP-Centric Modem may be configured, operated and monitored
using any of the following methods:
User Interface
Front Panel
Serial Remote
Control
Serial Command
Line Interface (CLI)
Telnet
Web Server
SNMP
15.3.3

Remote software/firmware upgrade via FTP

The IP Module uses 'flash memory' technology internally, and new firmware can be
uploaded to or from an external PC by FTP. This makes software upgrading very simple,
and updates can now be sent via the Internet, E-mail, or on disk. The upgrade can be
performed without opening the unit or having to be in the same physical location.
Connection
Local - Keypad
Local - Serial RS-232/RS-485
via Remote Control Port
Local - Serial RS-232 via
Console Port
Local or remote - Ethernet via
10/100 BaseT Traffic interface
Local or remote - Ethernet via
10/100 BaseT Traffic interface
Local or remote - Ethernet via
10/100 BaseT Traffic interface
Modem
Functions
ALL
ALL
ALL
ALL
ALL
ALL
15–2
Revision 4
MN/CDM570L.IOM
IP Module Reference
Functions
IP Address/Subnet Chapter 6
Mask only
IP Address/Subnet Chapter 14
Mask only
ALL Chapter 17
ALL Chapter 17
ALL Chapter 18
ALL Chapter 19
