CDM-570/570L Satellite Modem with Optional IP Module
Front Panel Operation
6.16.5

(INFO) FRAME (Framing and EDMAC information)

Examples:
Framing: Disabled
Framing:AUPC-Only,EDMAC2
Framing: AUPC+EDMAC2
Master,0240 (ENT or CLR)
Framing: AUPC+EDMAC
Slave, 0241 (ENT or CLR)
This screen shows EDMAC mode, and shows if the unit is EDMAC Master or Slave,
with the appropriate address. Pressing ENTER or CLEAR takes the user back to the
previous menu.
6.16.6

(INFO) INTFC (Interface information)

This screen shows details of the electrical interface type of the main data port. If RS422,
V.35 or RS232 is selected, the menu will also indicate the operation of RTS/CTS.
Pressing ENTER or CLEAR takes the user back to the previous menu. For example:
Interface: RS422
RTS/CTS Loop, No Action
Interface:G.703 E1-Unbal
HDB3
Interface: G.703 T1 B8ZS
533-655 feet(ENT or CLR)
Interface: IP
IEEE 802.3 Ethernet
(ENTER or CLEAR)
(ENTER or CLEAR)
(ENT)
(ENTER or CLEAR)
(ENT)
6–54
Revision 4
MN/CDM570L.IOM
