Self Diagnostic Test - GRAPHTEC CE7000 Series User Manual

15.6

Self Diagnostic Test

Operation status can be tested by self-diagnostic test by operating the sensors and switches following the
instruction on the screen.
Supplement
Diagnostic test can be performed only right after the power is turned on. DIAGNOSTICS cannot be selected from the menu once any
operation, such as loading media, is performed.
Operation
1
Confirm that the power is turned off.
2
Turn the power on without loading the media.
3
In the default screen, press the [PAUSE/MENU] key.
MENU screen is displayed.
4
Press the POSITION ( ) key (TEST).
TEST screen (1/2) is displayed.
5
Press the POSITION ( ) key.
TEST screen (2/2) is displayed.
Supplement
Perform the settings in Normal mode.
15-24
