When using Cutting Master 4
1
In Adobe Illustrator, select "Cutting Master 4" - "Cut/Plot"
from the File menu.
In Corel DRAW, select "Launch" - "Cut/Plot (CM4)" from
the tool bar.
* If using CorelDRAW version X7 or earlier, select from
the application launcher.
Before selecting the Cut/Plot, set the layer of printing
data to Hide.
2
"Cut/Plot" screen is displayed.
Check the "Hold in list".
Press the "Send".
Supplement
When the "Cut/Plot" screen is displayed for the
first time, the "Add Device" screen is displayed.
Follow the instructions on the screen to select
the model name to use.
•
For USB connection, select the "Graphtec
USB".
•
For network connection, select the "TCP/IP"
and then enter the IP address of the cutting
plotter.
•
The explanation here is limited to using a
personal computer instead of the server for
the data link server.
13-29
