Chapter 5: ARMS
(Advanced Registration Mark Sensing System)
ARMS (Advanced Registration Mark Sensing System) is a function to scan the registration mark drawn on
the media using sensors.
Tilt of the axes and distance can be adjusted with 2POINTS or 3 POINTS. 2 axes warp adjustment can be
adjusted in addition to axes adjustment (tilt) and distance adjustment with 4POINTS.
When cutting the outlines of the printed figure, and when re-cutting media, using ARMS to adjust for printing
position discrepancies, high precision cutting can be done.
It is possible to perform a multiple registration mark adjustment or segment area adjustment by linking with
the application software on the computer. See the operation guides of the application software about the
registration mark adjustment function linked with the application software.
This chapter describes the outline of the ARMS (Advanced Registration Mark Sensing System) and how to
setup and use the ARMS on the control panel.
PRODUCT SUMMARY
5.1 Outline of ARMS
5.2 Setting and Adjustment of ARMS
