Scan range necessary to detect the registration mark

The range of tool carriage and media movement needed to scan the registration mark is as following.
Do not print in the shaded area shown in the Figure below.
MARK TYPE 1
a
MARK TYPE 3
a
<For 3POINTS>
a
a
a=6mm
Registration mark scanning area
MARK TYPE 2
a
a
a
a
MARK TYPE 4
a
a
5-4
