Self Diagnostic Test - GRAPHTEC CE6000-120AP User Manual

12.6

Self Diagnostic Test

Operation status can be tested by self diagnostic test by operating the sensors and switches following the
instruction on the screen.
Supplement
Diagnostic test can be performed only right after the power is turned on. DIAGNOSTICS cannot be selected from the menu once
any operation, such as loading media, is performed.
Operation
1
Confirm that the power is turned off.
2
Turn the power on without loading the media.
3
Press the [PAUSE/MENU] key in the default screen.
MENU screen is displayed.
4
Press the POSITION ( ) key (TEST).
TEST menu screen (1/2) is displayed.
5
Press the POSITION ( ) key.
TEST menu screen (2/2) is displayed.
6
Press the [1] key (DIAGNOSTICS).
DIAGNOSTICS start screen is displayed.
Supplement
Perform the settings in Normal menu.
12-21
