Normal Mode - GRAPHTEC CE7000 Series User Manual

Normal mode

Menu items
TOOLS SETTING
(TOOL)
ARMS SETTING
(ARMS)
AREA PARAMETERS
(AREA)
MEDIA SETTING
(MEDIA)
INTERFACE
(I/F)
ADVANCE
(ADV.)
TEST
(TEST)
Setting item
TOOL OFFSET ADJ.
STEP PASS
OFFSET FORCE
OFFSET ANGLE
DATA SORTING
CONDITION PRIORITY
TOOL UP MOVE
MOVING SPEED
TOOL UP HEIGHT
BLADE WEAR ALARM SETUP
INITIAL B. ANGLE POSITION
SCAN MODE
RECOMMENDED SETTINGS
MARK LINE CHECK
SENSOR OFFSET ADJ.(X)
SENSOR OFFSET ADJ.(Y)
MARK AUTO SCAN
SENSING SPEED
TEST ARMS SENSOR
MARK SCAN MODE
SCALE
ROTATE
MIRROR
AREA SET LOWER LEFT
AREA SET UPPER RIGHT
EXPAND
PRE FEED FEED LENGTH
AUTO PRE FEED
AUTO PRE FEED FEED LENGTH
PAGE LENGTH
INITIAL FEED
FEED SPEED
PANEL CUTTING
DIVIDE LENGTH
TAKE-UP
HP-GL ORIGIN POINT
HP-GL MODEL EMULATED
GP-GL STEP SIZE
RS-232C (SWITCHING SETTING NUMBERS)
RS232C: FORWARDING CONDITION
BAUD RATE/DATA BIT/
PARITY/HARDWIRE HANDSHAKE
LAN DHCP
LAN IP
LAN SUBNET MASK
LAN GATEWAY
COMMAND ':',';'
COMMAND 'W'
CIRCLE RESOLUTION
MOVE STEP
LANGUAGE SELECTION
LENGTH UNIT
BEEP FOR KEY OPE.
POSI. KEY SPEED + SLOW KEY
POSI. KEY SPEED
PAUSE/MENU KEY SETTING
LCD CONTRAST
MEDIA SENSOR
PUSH ROLLER SENSOR
FAN POWER
NO SETTINGS
–
1
7
30
OFF
PROGRAM
DISABLED
AUTO
NORMAL POSITION
OFF
2mm BELOW
MODE1
–
–
0
0
ON
30cm/s
–
OFF
1
OFF
OFF
(DEFAULT)
(DEFAULT)
(DEFAULT)
1m
OFF
1m
200.0cm (CE7000-40)
500.0cm (CE7000-60/130/160)
OFF
NORMAL POSITION
OFF
100.0cm
OFF
LOWER LEFT
7586
0.100mm
No.1
RS-232C No.1 : 9600/8/NONE//HARD
RS-232C No.2 : 9600/7/EVEN//HARD
RS-232C No.3 : 9600/8/EVEN/XonXoff
RS-232C No.4 : 9600/8/EVEN/XonXoff
OFF
192.168.0.1
255.255.255.0
192.168.0.254
ENABLED
TOOL UP
DEFAULT
0.1mm
Select when initially turning on power
Select when initially turning on power
ON
1cm/s
10cm/s
PAUSE
0
ENABLED
ENABLED
NORMAL POSITION
–
A-18
Initial value
