12.1

Select Connection Destination

Dedicated data created previously with application software etc. is output to the cutting plotter.
It can be saved in USB memory and output the data saved in USB memory, or output via server (personal
computer) using network (LAN) cable or USB cable.
Operation
1
Press the [PAUSE/MENU] key.
MENU screen is displayed.
2
Press the POSITION ( ) key (LINK).
DATA LINK screen (1/2) is displayed.
3
Press the [1] key (DESTINATION).
DESTINATION screen is displayed.
4
Press the [1] key (USB MEMORY), the [2] key (SERVER
(USB)) or the [3] key (SERVER (LAN)).
5
Confirm the setting and press the [ENTER] key (SET).
Setting will be confirmed and it will return to DATA LINK screen (1/2).
6
Press the [PAUSE/MENU] key.
It will return to default screen.
Supplement
Perform the settings in Normal mode.
12-2
