9.4

Connecting with RS-232C

For the RS-232C settings, you can recall any setting by storing the four different setting types of 1 to 4.
See "Switching the setting number you want to use" to recall the setting you want to use and See "Changing/
Storing the RS - 232C Setting" to change and store the settings.
* RS-232C interface depends on the sales area. For details, please contact the distributor where you purchased.
* When the RS-232C interface is not equipped, the menu will not be displayed.

Switching the setting number you want to use

Operation
1
Press the [PAUSE/MENU] key.
MENU screen is displayed.
2
Press the POSITION ( ) key (I/F).
INTERFACE screen (1/3) is displayed.
3
Press the POSITION ( ) key.
INTERFACE screen (2/3) is displayed.
4
Press the [2] key (RS-232C).
RS-232C setting screen is displayed.
Supplement
Perform the settings in Normal mode.
Supplement
It will return to INTERFACE screen (2/3) without
changing the settings when you press the [ESC]
key (CANCEL).
9-10
