12.3

Output with a Bar Code

The information related to the output file is bar-coded using the Cutting Master4 and Graphtec Pro Studio, etc. and
the barcode can be printed with the design and the registration marks.
When cutting with the cutting plotter, the bar code is scanned and the cut data (XPF) that has been saved to a
USB memory that matches the bar code is detected.
Standard bar code
Operation
1
Insert the USB memory that saved the dedicated data to the
plotter.
2
Press the [PAUSE/MENU] key.
MENU screen is displayed.
3
Press the POSITION ( ) key (LINK).
DATA LINK screen (1/2) is displayed.
Bar code
Start mark
12-5
Roll paper bar code
Bar code Start mark
Supplement
Perform the settings in Normal mode.
