GRAPHTEC CE7000 Series User Manual page 185

7
Press the [2] key (TYPE No.).
TYPE No. screen is displayed.
8
Press the POSITION (
9
Confirm the setting and press the [ESC] key (PREVIOUS).
TYPE No. will be selected and it will return to CUT LINE PATTERN
screen.
10
Press the POSITION ( ) key (UP MODE).
UP MODE screen is displayed.
11
Press the POSITION (
12
Confirm the setting and press the [ESC] key (PREVIOUS).
It will return to UP MODE screen.
) keys and select the TYPE No.
) keys and set the UP MODE.
7-17
Supplement
•
CUT L and UP L is displayed when the TYPE
No. 0-7 is selected. Also, you will be able to
set the UP MODE.
•
Setting for all becomes enabled when USER
is selected.
•
Nothing will be displayed when "OFF" is
selected.
Supplement
You can set the range between 1 and 38, and
"UP".
Supplement
•
Value set here will be the cut force for the
uncut part of the perforated lines. Tool will be
raised when set to "UP".
•
Normally, input the smaller value than the
FORCE for cutting to make it half cutting.
