Skew Scanning - GRAPHTEC CE7000 Series User Manual

12.6

Skew Scanning

When continuous operation is performed, it is possible to set how much skewis allowed by detecting media skew
by comparing the start mark positions of the start page and the current page.
For continuous operation, see "Application of bar code cut (continuous operation)".
Operation
1
Press the [PAUSE/MENU] key.
MENU screen is displayed.
2
Press the POSITION ( ) key (LINK).
DATA LINK screen (1/2) is displayed.
3
Press the POSITION ( ) key.
DATA LINK screen (2/2) is displayed.
4
Press the [3] key (AUTOMATIC SKEW DETECTION).
AUTOMATIC SKEW DETECTION screen is displayed.
5
Press the [1] key (5 mm), the [2] key (10 mm) or the [3] key (15
mm).
Supplement
Perform the settings in Normal mode.
Supplement
During continuous operation, you can select
from 5 mm, 10 mm or 15 mm for the skew
tolerance.
12-12
