When using Graphtec Pro Studio
1
Click on the "Cut Contour" icon.
2
The "Cut Contour" screen is displayed.
Select the "Hold in list" from the "Send mode".
Press the "Send".
3
Switch to Production Manager.
Confirm that the sent file is held in the "Hold" item.
Supplement
When the "Cut Contour" screen is displayed
for the first time, the "Add Device" screen is
displayed. Follow the instructions on the screen
to select the model name to use.
•
For USB connection, select the "Graphtec
USB".
•
For network connection, select the "TCP/IP"
and then enter the IP address of the cutting
plotter.
•
The explanation here is limited to using a
personal computer instead of the server for
the data link server.
13-28
