13.2

Basic operation of bar code

This section describes how to print and cut with the data link function of cutting plotter after creating standard bar
code in dedicated application.
The procedure to read the data linked to the bar code from the USB memory is explained.
Because the procedure differs for each application, refer to the following depending on the application to be used.
•

Graphtec Pro Studio / Cutting Master 4

Step 1: Create registration mark (alignment mark) data and design data for printing and cutting.
Step 2: Add bar code data.
Step 3: Print design data.
Step 4: Save cutting data in USB memory.
Step 5: Cut the printed media.
Supplement
•
Graphtec Studio does not have a bar code function.
Graphtec Pro Studio / Cutting Master 4
Step 1:
Create registration mark (alignment mark) data and design data for printing and cutting.
See "13.1 Basic operation of printing and cutting" to create design with registration marks for printing and cutting.
Step 2: Add bar code data.
For the data link, it is necessary to add bar code data in order to link the printed print data for printing and cutting
with the cutting data saved in the USB memory.
Operation
2-
1 Create a bar code to use the data link function.
13-15
