GRAPHTEC CE7000 Series User Manual page 139

MARK TYPE 1
a
MARK TYPE 1
(There are central registration marks.)
a
a
MARK TYPE 3
a
a=6mm
Supplement
•
Clean any dirt or foreign objects from the media. Any dirt or foreign object might be scanned mistakenly as registration mark.
•
Plot the registration mark in contrast easy to scan, such as black lines on white background. Adjust the scanning level of the sensor
if you need to use the colored or glossy media. (See "Setting MARK SCAN Mode". )
<For 4POINTS>
a
a
a
a
Registration mark scanning area
MARK TYPE 2
a
a
a
a
MARK TYPE 2
(There are central registration marks.)
a
a
a
a
a
a
MARK TYPE 4
a
a
