GRAPHTEC CE7000 Series User Manual page 330

A.1
Main Specifications
CPU
Configuration
Drive
Max. Cut Area
Guaranteed precision
cutting area
*1
Mountable media width
*3
Available roll media
diameter
The number of push rollers
Max. cutting speed
Specifiable speeds
(cm/s)
Max. cutting force
Min. character size
Mechanical resolution
Programmable resolution
Repeatable accuracy
*1
Number of cutters/pens
Usable pen type
Compatible media
Interface
Buffer memory
Resident command sets
LCD display
Power supply
Power consumption
Operating environment
Guaranteed accuracy
environment
External dimensions
(Approx.)
(W × D × H)
Weight ( Approx.)
*1: Varies depending on the type of Graphtec-authorized film and the cutting conditions.
*2: When using basket.
*3: Describes the usable paper width. The accuracy of minimum media width is the width in parentheses ( ).
*4: HP-GL is a registered trademark of the US Hewlett Packard Company.
*5: Roll-medium tray or stand is included.
*6: RS-232C interface is optional depending on region. For details, please contact the distributor where you purchased.
CE7000-40
32bit CPU
Grit-rolling plotter
Digital servo
375 mm × 50 m 603 mm × 50 m
355 mm × 2 m 583 mm × 5 m
Min: 50 mm Min: 50 mm
Max: 484 mm Max: 712 mm
Max. diameter: 180 mm, Min. diameter: 76 mm
2 2
60 cm/s (All directions) 90 cm/s (45°direction)
1 to 10, 15, 20, 25, 30, 1 to 10, 15, 20, 25, 30,
35, 40, 45, 50, 55, 60, 35, 40, 45, 50, 55, 60,
64
4.41N (450gf)
5 mm (0.197 in.) alphanumeric Helvetica med. Font
0.005mm
GP-GL : 0.1/0.05/0.025/0.01 mm
HP-GL : 0.025 mm
*4
0.1 mm/in unit of 2 m (Designated Film and Cut Conditions)
1 pc.
Water-based fiber-tip and oil-based ballpoint
Mono-vinyl chloride media, fluorescent media, and reflective media up to 0.25 mm thick (Excluding high-
intensity reflective film)
USB2.0 (Full Speed) , Ethernet 10BASE-T/100BASE-TX, RS-232C
2 MB
GP-GL/HP-GL (Control panel switching, Auto switching)
*4
Graphic type (240 × 128 dot)
AC100-120V, AC200V-240V 50/60Hz
100 VA or less
10 to 35℃, 35 to 75 % R.H. (non-condensing)
16 to 32℃, 35 to 70 % R.H. (non-condensing)
772 mm × 460 mm × 1005 mm × 582 mm ×
313 mm 1092 mm
13 kg 22 kg
*5
CE7000-60 CE7000-130
1270 mm × 50 m
1250 mm × 5 m
*2
Min: 50 mm
Max: 1372 mm
4
100 cm/s (45°direction)
1 to 10, 15, 20, 25, 30, 35, 40, 45, 50, 55, 60, 65,
70, 71
*1
1704 mm × 811 mm ×
1215 mm
*5
51 kg
*5 *5
A-2
CE7000-160
1524 mm × 50 m
1504 mm × 5 m
*2
Min: 50 mm
Max: 1626 mm
4
*6
1916 mm × 811 mm ×
1215 mm
*5 *5
55 kg
*5
*2
