Chapter 7:
Setting Regarding Cutting Quality
There are times that ideal cutting may not be possible, such as the lines may shift, corners deform, or uncut
sections occur, due to the characteristics of the media (thickness, how hard it is, etc.) or the shape of the
blades, when the actual cutting is done. Adjust the moving speed and force of the tool, and the control
method to prevent these problems.
This chapter describes the setting regarding the quality of the cutting.
PRODUCT SUMMARY
7.1 Cutting the Corner of Thick Media Sharp
7.2 Setting the Step Pass
7.3 Setting the Offset Angle
7.4 Setting the Distance Adjust
7.5 Setting Cut Line Pattern
7.6 Setting Initial Blade Control Position Adjust
7.7 Setting the OFFSET FORCE
7.8 Setting Adjustment Between the Tools
