GRAPHTEC CE7000 Series User Manual page 267

Step 4: Cut the printed media.
Cut the media prepared in Step 3 with the cutting plotter.
Operation
4-
1 Load the printed media on the cutting plotter.
MARK TYPE 1
4-
2 Open the "Configure Cut Job" screenl.
Select the "By Color" from the "Apply Conditions" and select
the color to cut.
4-
3 Open the "Page" screen.
Set the ROTATE to "0°" to match the setting direction of the
media.
MARK TYPE 2
13-13
Supplement
For loading media, see "Loading Media (Paper
or Marking Film)".
Supplement
The ROTATE can be set only when using
4POINTS.
For other registration marks, load the media
according to the orientation of the preview.
