GRAPHTEC CE7000 Series User Manual page 129

It will copy in following order when COORDINATE AXES ROTATION is set.
Copy origin point
First cut
Origin point
Operation
1
Plot (cut) the data you want to copy once.
Cutting data is stored in the buffer memory.
2
Press the POSITION (
carriage to the position to copy.
3
Press the [COPY] key
COPY MODE screen is displayed.
4
Press the [1] key (MEDIA CHANGE MODE).
MEDIA CHANGE MODE screen is displayed.
5
Press the [1] key (OFF).
Confirm the settings and it will return to the COPY MODE screen.
Third copy
First copy Second copy
Copy
space
Copy space
Fifth copy Sixth copy
) keys and move the tool
Fourth copy
Supplement
•
•
•
•
4-11
When setting the copy interval, set "MEDIA
CHANGE MODE" to OFF.
NO DATA FOR COPY IN BUFFER!" is
displayed if there is no data in the buffer
memory. Send the cutting data.
If too much data is sent from the buffer
memory, "1 copy in the Copy mode buffer!"
will be displayed.
If the data to be copied is larger than the
cutting area, "Cannot copy, the valid area is
too small" will be displayed.
