12.2

Data Link with USB Memory

Dedicated data created previously with application software etc. can be saved in the USB memory and output
from the cutting plotter.
Data link can be performed by selecting data from the plotter menu.
Supplement
•
File name
• Only 1-byte alphanumeric characters (ASCII) are supported.
• Windows prohibited characters (¥, /, /, ;, *, ?, ", <, >, |, etc. are not available.
• Limit of the number of display characters is 25 characters. More characters than 25 can be displayed by scrolling.
• Extension is "xpf" and "plt".
•
Scroll is displayed after a few moments after selecting the item.
•
The folder is surrounded by '<' and '>'.
•
Name is sorted in ascending order.
•
Files and folders can be obtained up to 64.
•
Files in the second level folder is not available.
Operation
1
Insert the USB memory that saved the dedicated data to the
plotter.
2
Press the [PAUSE/MENU] key.
MENU screen is displayed.
3
Press the POSITION ( ) key (LINK).
DATA LINK screen (1/2) is displayed.
4
Press the [1] key (DESTINATION).
DESTINATION screen is displayed.
Supplement
Perform the settings in Normal mode.
12-3
